P_SI_0038

Fig. 39: Cross-section through the liquid end

1 Suction valve

2 Diaphragm

3 Discharge valve

4 Dosing head

5 Backplate

13 Safety diaphragm

Data Value Unit

Tightening torques for dosing head

screws:

4.5 ... 5.0 Nm

Tightening torques

Carrying out repairs
