ProMinent Sigma 1 S1Cb User Manual

P_SI_0184_SW
Fig. 42: Representation is not strictly binding - dimensions in mm
Type Connector A B C D E F ØG I K
12017,
12035,
10050
PVT
DN 10 234 87 G1 3/4
M
63 82*/ 79 84 96 131 62
12017,
12035,
10050
SST
DN 10 231 89 G1 3/4
M
62 78 88 108 100 45
10022,
10044,
07065
PVT
DN 10 234 87 G1 3/4
M
63 82*/ 79 84 96 131 62
10022,
10044,
07065
SST
DN 10 231 89 G1 3/4
M
62 78 88 108 100 45
07042,
04084,
04120
SST
DN 15 243 78 G1 M 68 99*/ 89 74 122 138 63
07042,
04084,
04120
PVT
DN 15 243 78 G1 M 67 88 88 124 112 51
* with bleed valve
Sigma X Control type – Sigma/ 1 - S1Cb with hygienic pump head
Sigma X Control type – Sigma/ 1 - S1Cb,
“liquid end on left” design
Dimensional drawings
91
