5.4.2 Advanced – Hardware Monitor
Menu Path Advanced > Hardware Monitor
The Hardware Monitor allows users to monitor the health and status of the system
such as CPU temperature, system temperature and voltage levels in supply.
Hardware Monitor Screen
BIOS Setting
Options
Description/Purpose
CPU Temperature
No changeable options
Displays the processor's temperature.
System Temperature
No changeable options
Displays the system's temperature.
VCORE
No changeable options
Detects and displays the VCORE
CPU voltage.
VCC5V
No changeable options
Detects and displays 5V voltage.
VCC12
No changeable options
Detects and displays 12V voltage.
VDDQ
No changeable options
Detects and displays VDDQ voltage.
VCC3V
No changeable options
Detects and displays 3V voltage.
VSB3V
No changeable options
Detects and displays VSB3V voltage.
VSB5V
No changeable options
Detects and displays VSB5V voltage.
VBAT
No changeable options
Detects and displays the battery
voltage.
