BATTERY
The 9V battery will last for about 40,000 shots. Please be
aware that there are substantial differences in performance
between different brands of batteries. Use of high quality
alkaline or lithium ion batteries is recommended for maximum
battery life. If you plan not to use your marker for a long
period of time (a month), it is recommended that you remove
the battery from the marker. When the battery voltage starts
to go too low, the marker will not fi re with every trigger pull.
For tournament use, it is recommended to change the battery
for each tournament.
CHANGING THE BATTERY
The battery is housed on the right side of the grip frame. To
access the battery, remove the three screws holding the right side grip panel down. Use a 3⁄32”
Allen key. When inserting a new battery notice the + and - marks on the board. The positive lead
of the 9V battery goes to the left and the negative lead to the right.
NOTE: If the marker will not function with the eye on, there is a good chance the battery needs
to be changed.
• To make the trigger pull stiffer, turn the Allen wrench clockwise or in.
• To make the trigger pull lighter, turn the Allen wrench counterclockwise or out.
TO ADJUST TRIGGER REACH (SEE FIGURE 1)
To adjust, simply loosen the two 6-32 screws (4) using a 1/16” Allen wrench. You do not have to
remove the screws from the trigger. Now the front of the trigger (shown in green) should rotate
freely while the back of the trigger remains relatively stationary. When the desired reach angle
has been achieved, tighten the two 6-32 screws snugly.
