Page #70 background imageLoading...
Page #70 background image
Specifications
Model XQ30
SKU 77378
Microbolometer
Type Uncooled
Resolution, Pixels 384x288
Pixel Pitch, µm 17
Frame Rate, Hz 50
Optical Characteristics
Monocular magnification, x 5
Recommended daylight optics
magnification, x
1.5-4
Lens F30/1.2
Digital Zoom, x -
Eye Relief, mm/inch 18 / 0.7
Eye Relief Diameter, mm/inch 6 / 0.24
Field-of-view (Horizontal), deg/m per
100 m
12.4 / 21.8
Eyepiece Focusing Range, Diopter +5/-5
Detection Range (animal height 1.7 m),
m/y
900 / 984.25
Minimum Observation Distance, m/y 15 / 16.4
Display
Type AMOLED
Resolution, Pixels 1024x768
Operational Characteristics
Power Supply, V 3-4.2
Battery type/Capacity/Rated Output
Voltage
Li-Ion Battery Pack APS 5 / 4900 mAh
/ DC 3.7 V
External Power Supply 5 V (USB Type-C)
Max. Battery Pack Life (at t = 22 °C),
hours*
6
