ORiNOCO
®
802.11n Access Points - Software Management Guide 100
3. Click Retrieve after selecting the file type, the Download screen appears.
Figure 6-12 Download
4. Right-click the Download link to save or retrieve the file to the desired location.
: When the device is operational with factory default settings, there is no Config file present and hence it cannot be
retrieved.
6.2.3.2 Retrieve from Device by using TFTP
To retrieve Configuration files, Event Logs and Text Based Templates from the device by using TFTP, follow the following steps:
1. Navigate to MANAGEMENT > File Management > Retrieve from Device > TFTP. The configuration screen
appears:
Figure 6-13 Retrieve From Device by using TFTP
2. Configure the following parameters:
Select the parameters to exclude and click Create Profile. Next, click Retrieve.
See Update Configuration, to update the target device with the retrieved config
profile. Once updated, the target device comes up with the configuration of the
master device, by excluding the selected unique parameters.
: Config Profile is applicable only to the compatible devices.
Parameter Description
Server IP Address Enter the TFTP server IP address.
File Name Enter the file (including the file extension) to be retrieved from the device.
