10 SOLAREG II technical data
Casing
Material 100% recyclable ABS casing for wall mounting
Dimensions (L x W x H) in mm,
weight
175 x 134 x 56; approx. 360 g
Protection class IP20 according to DIN 40050
Electrical specications
Supply voltage AC 230 V/50 Hz, -10 – +15%
Radio interference class N (as dened by VDE 0875)
Max. cable cross-section, 230 V
connections
2.5 mm² ne-/single-wire
Temperature sensor
measuring range
PT1000, 1 kΩ at 0 °C
- 30 °C .. +250 °C
Test voltage
4 kV 1 min according to EN 60730/DIN, VDE
0631, IEC 60664/IEC
Output voltage
Power per output
Control signal PWM (O1):
Control signal ANA (O1:
230 V AC
1 A / approx. 230 VA for cos φ = 0.7-1.0
2 kHz, max. 10 mA
0..10 V, max. 5 mA
Fuses
Fine-wire fuses 5 x 20 mm, 2A (T)
2 amperes, time lag fuse
Other
Operating temperature 0 – + 50 °C
Storage temperature -10 – + 65 °C
Humidity max. 60 %
11 PT1000 resistance table
Temperature sensors can be checked for proper function by using an ohmmeter
and consulting the following temperature resistance table:
Temperature
in °C
Resistance in
ohms
Temperature
in °C
Resistance in
ohms
-30 882 60 1232
-20 921 70 1271
-10 960 80 1309
0 1000 90 1347
10 1039 100 1385
20 1077 120 1461
30 1116 140 1535
40 1155 200 1758
50 1194
Specifications subject to
change as technical
improvements are made.
