Description
Description
Overview
3
LEDs indicate:
- Alarm condition
- Measurement error
- Battery charge status.
5
A / B - Measuring chan-
nels for analog signals and
charging sockets.
6
Temperature - interface for
thermo couple type K
7
Digital input / analog
output for:
- Trigger / RPM sensor
- Data transfer via RS 232
- Headphone / Oscilloscope
- Strobe control
8
Communication
via Ethernet / USB
1
Full color display - large,
backlit, high-contrast.
2
Light sensor controls key
board illumination.
4
Keyboard can be com-
fortably operated with
the thumb.
3
4
1
2
7
5 6
