DRS4 Evaluation Board User’s Manual
Page 21 of 43
For test purposes, an internal 100 MHz reference clock signal can be connected to all
channels via the “Config” menu:
The effect of the timing calibration can be tested by turning the timing calibration on and off
via the “Apply Timing Calibration” check box.
