PSI DRS4 - DRS4 Evaluation Board V5 Bill of Materials

DRS4 Evaluation Board User’s Manual
Page 37 of 43
6. DRS4 Evaluation Board V5 Bill of Materials
Count
Name
RefDes
Pattern
Value
Description
1
24LC128_SN
U38
SO-G8
Serial EEPROM
1
A25L016M
U26
SO-8-SM
Serial Flash Memory
1
AD8061ART
U22
SOT23-5
300MHz Voltage Feedback Amplifier
3
AD8605ART
U18
SOT23-5
300MHz Voltage Feedback Amplifier
AD8605ART
U19
SOT23-5
300MHz Voltage Feedback Amplifier
AD8605ART
U20
SOT23-5
300MHz Voltage Feedback Amplifier
1
AD9245
U21
LFCSP_VQ_32
14-bit ADC
4
ADCMP601
U13
SC70-6
Fast comparator
ADCMP601
U14
SC70-6
Fast comparator
ADCMP601
U15
SC70-6
Fast comparator
ADCMP601
U16
SC70-6
Fast comparator
4
ADG918BCP
U1
CP-8-2
Wideband analog switch
ADG918BCP
U3
CP-8-2
Wideband analog switch
ADG918BCP
U7
CP-8-2
Wideband analog switch
ADG918BCP
U9
CP-8-2
Wideband analog switch
1
ADR03
U24
SC70-5
2.5V Precision voltage reference
1
ASEMP-3.2X2.5
Q4
24.000 MHz
Clock oscillator
1
ASEMP-3.2X2.5
Q3
100 MHz
Clock oscillator
4
BAV99
U28
SOT23-3
High speed double diode
BAV99
U30
SOT23-3
High speed double diode
BAV99
U32
SOT23-3
High speed double diode
BAV99
U34
SOT23-3
High speed double diode
1
CAPP
C138
CAPP
220u
4
CAP_0402
C51
402
10n
CAP_0402
C52
402
10n
CAP_0402
C55
402
10n
CAP_0402
C56
402
10n
23
CAP_0402
C7
402
100n
CAP_0402
C8
402
100n
CAP_0402
C15
402
100n
CAP_0402
C16
402
100n
CAP_0402
C21
402
100n
CAP_0402
C22
402
100n
CAP_0402
C31
402
100n
CAP_0402
C32
402
100n
CAP_0402
C39
402
100n
CAP_0402
C40
402
100n
CAP_0402
C45
402
100n
CAP_0402
C46
402
100n
CAP_0402
C49
402
100n
CAP_0402
C50
402
100n
CAP_0402
C53
402
100n
CAP_0402
C135
402
100n
CAP_0402
C157
402
100n
CAP_0402
C158
402
100n
CAP_0402
C164
402
100n
CAP_0402
C165
402
100n
CAP_0402
C166
402
100n
CAP_0402
C167
402
100n
CAP_0402
C168
402
100n
5
CAP_0402
C58
402
100p
CAP_0402
C59
402
100p
CAP_0402
C60
402
100p
CAP_0402
C62
402
100p
CAP_0402
C63
402
100p
24
CAP_0402
C1
402
220n
CAP_0402
C2
402
220n
