DRS4 Evaluation Board User’s Manual
Page 40 of 43
CAP_1206
C97
1206
10u
CAP_1206
C122
1206
10u
CAP_1206
C123
1206
10u
CAP_1206
C136
1206
10u
CAP_1206
C141
1206
10u
CAP_1206
C155
1206
10u
1
CAP_1206
C139
1206
22u
1
CAP_1206
C131
1206
100n
1
CAP_1210
C142
1210
47u
2
CAP_1210
C57
1210
100u
CAP_1210
C61
1210
100u
1
CONN_MOLEX_J
TAG_FPGA
J45
DIL14P_2MM
JTAG
1
CY7C68013-56
U37
SSO-G56
USB microcontroller
1
DRS4_76
U17
QFN-76
Domino Ring Sampling Chip V4
2
FP_1MM
FP1
FP_1MM
FP_1MM
FP2
FP_1MM
2
IND_0603
L14
603
82nH
IND_0603
L15
603
82nH
8
IND_0603
L1
603
220nH
IND_0603
L2
603
220nH
IND_0603
L3
603
220nH
IND_0603
L4
603
220nH
IND_0603
L5
603
220nH
IND_0603
L6
603
220nH
IND_0603
L7
603
220nH
IND_0603
L8
603
220nH
1
IND_1008
L11
1008
10u
2
IND_1812
L9
1812
10u
IND_1812
L10
1812
10u
2
JMP2MM
JP1
TP50MIL
~WP
Jumper
JMP2MM
JP2
TP50MIL
~WP
Jumper
1
LED_PLCC-4
U39
PLCC-4
blue
LED
1
LED_PLCC-4
U40
PLCC-4
green
LED
1
LED_PLCC-4
U41
PLCC-4
yellow
LED
1
LMZ10503
U43
TO-PMOD-7
800mA and 1A Low Dropout Positive Regulator 2.85V,
3.3V, 5V, and Adjustable
1
LP2985-2.5
U45
SOT23-5
800mA and 1A Low Dropout Positive Regulator 2.85V,
3.3V, 5V, and Adjustable
1
LP2985-3.3
U44
SOT23-5
800mA and 1A Low Dropout Positive Regulator 2.85V,
3.3V, 5V, and Adjustable
1
LTC2600
U23
SSOP16
16-bit octal DAC
1
MAX6662
U25
SO-G8
SPI Temperature Sensor
4
MCX-90
J18
MCX-90
MCX connector 90 deg.
MCX-90
J30
MCX-90
MCX connector 90 deg.
MCX-90
J39
MCX-90
MCX connector 90 deg.
MCX-90
J41
MCX-90
MCX connector 90 deg.
4
RCLAMP0502B
U5
SOT523
Protection diode
RCLAMP0502B
U6
SOT523
Protection diode
RCLAMP0502B
U11
SOT523
Protection diode
RCLAMP0502B
U12
SOT523
Protection diode
1
REG1117-1.2
U47
SOT223
800mA and 1A Low Dropout Positive Regulator 2.85V,
3.3V, 5V, and Adjustable
19
RES_0402
R1
402
0E
RES_0402
R3
402
0E
RES_0402
R37
402
0E
RES_0402
R38
402
0E
RES_0402
R41
402
0E
RES_0402
R43
402
0E
RES_0402
R77
402
0E
RES_0402
R78
402
0E
RES_0402
R99
402
0E
RES_0402
R100
402
0E
RES_0402
R101
402
0E
RES_0402
R102
402
0E
RES_0402
R103
402
0E
