DRS4 Evaluation Board User’s Manual
Page 43 of 43
2
RES_0603
R110
603
22E
RES_0603
R112
603
22E
1
RES_0603
R158
603
22E
1
RES_0603
R156
603
23.7k
1
RES_0603
R141
603
49.9E
1
RES_0603
R154
603
75k
1
RES_0603
R113
603
100E
2
RES_0603
R137
603
100k
RES_0603
R138
603
100k
1
RES_0603
R92
603
130E
2
RES_0603
R144
603
220E
RES_0603
R145
603
220E
1
RES_0603
R87
603
390k
2
RES_0805
R88
805
0E
RES_0805
R89
805
0E
2
RES_0805
R107
805
0E
RES_0805
R136
805
0E
1
RES_0805
R96
805
1k
8
RES_0805
R121
805
51E
RES_0805
R122
805
51E
RES_0805
R125
805
51E
RES_0805
R126
805
51E
RES_0805
R129
805
51E
RES_0805
R130
805
51E
RES_0805
R134
805
51E
RES_0805
R135
805
51E
1
RES_1206
R157
1206
120E
4
SMA_SMD_S
J1
SMA_SMD_S
SMA-Coaxial Connector, PCB right angle receptacle
SMA_SMD_S
J2
SMA_SMD_S
SMA-Coaxial Connector, PCB right angle receptacle
SMA_SMD_S
J4
SMA_SMD_S
SMA-Coaxial Connector, PCB right angle receptacle
SMA_SMD_S
J5
SMA_SMD_S
SMA-Coaxial Connector, PCB right angle receptacle
1
SN74LVC1G17
U48
PDSO-G5
Dual Positive-Edge-Triggered D-Type Flip-Flop
4
SN74LVC1T45DB
U27
SOT23-6
SN74LVC1T45DB
U29
SOT23-6
SN74LVC1T45DB
U31
SOT23-6
SN74LVC1T45DB
U33
SOT23-6
4
THS4508
U2
THS4509
Low noise differential amplifier
THS4508
U4
THS4509
Low noise differential amplifier
THS4508
U8
THS4509
Low noise differential amplifier
THS4508
U10
THS4509
Low noise differential amplifier
1
TPS79625
U46
SOT223-5
800mA and 1A Low Dropout Positive Regulator 2.85V,
3.3V, 5V, and Adjustable
1
USB_CONN_B
U35
USB_CONN_B
USB Connector
1
XC3S400-TQ144
U36
TQFP144
FPGA
1
XCF02S-V020
U42
TSSOP20
FPGA Flash PROM
