PSL PQube - Page 113

PQube User Manual 2.1
Page 113 of 113
101
Nominal frequency
Float
Hertz
102
PT (potential
transformer) ratio
Float
-
95
CT (current
transformer) ratio
Float
-
96
PQube serial
number
Float
-
PQube serial number, without leading
“P” and leading zeros
97
AN1 (Analog 1-E)
multiplier
Float
-
98
AN2 (Analog 2-E)
multiplier
Float
-
99
Current basis for
TDD
Float
RMS Amps
Used for calculating IEEE 519 Current
TDD, and for setting the maximum
current of interest.
100
Power
configuration
Integer
-
0 = single-phase L1-N
1 = single-phase L1-L2
2 = split single-phase
3 = Star / Wye
4 = Delta
5 = Split-phase Delta
255 = Not yet determined
101
Ground Point
102
N-minutes
