74
Harmonic – L2
current
Float
RMS Amps
Harmonic order specified in 166
75
Harmonic – L3
current
Float
RMS Amps
Harmonic order specified in 166
76
Harmonic – L1-
N voltage angle
Float
degrees
Harmonic order specified in 166
77
Harmonic – L2-
N voltage angle
Float
degrees
Harmonic order specified in 166
78
Harmonic – L3-
N voltage angle
Float
degrees
Harmonic order specified in 166
79
Harmonic – L1
current angle
Float
degrees
Harmonic order specified in 166
80
Harmonic – L2
current angle
Float
degrees
Harmonic order specified in 166
81
Harmonic – L3
current angle
Float
degrees
Harmonic order specified in 166
82
Harmonic order
of interest
Integer
Range: 1-50, selected by user on PQube
harmonic meters screens – defaults to
3
rd
harmonic
83
GPS status
Integer
0 = not installed
1 = not locked
2 = locked onto satellites and operating
84
GPS latitude
Float
degrees
Range: ±90.0000° from equator
85
GPS longitude
Float
degrees
Range: ±180.0000° from prime meridian
86
GPS number of
satellites
Integer
Count of acquired satellites
87
(Not used)
88
IEC or GB
Unbalance – V-
Float
Percent
Fundamental negative-sequence
voltage, as a percentage of fundamental
positive-sequence voltage
89
IEC or GB
Unbalance – A-
Float
Percent
Fundamental negative-sequence
current, as a percentage of fundamental
positive-sequence current
90
IEC or GB
Unbalance – V0
Float
Percent
Fundamental zero-sequence voltage, as
a percentage of fundamental positive-
sequence voltage
91
IEC or GB
Unbalance – A0
Float
Percent
Fundamental zero-sequence current, as
a percentage of fundamental positive-
sequence current
92
DC Power
Float
Watts
DC volts multipled by DC amps
93
DC Energy
Float
Wh
DC energy accumulated since [date]
94
User counter
counts
Long
Long
(none)
Number of times the Analog or Digital
Input channels were triggered since
[date]
Static Information
Offset
Register
Format
Units
Comments
95
PQube Firmware –
Major rev
Integer
-
Typically formatted as “1.1.2” or similar
– Major.Minor.Bugfix
96
PQube Firmware –
Minor rev
Integer
-
97
PQube Firmware –
Bug fix rev
Integer
-
98
PQube Firmware
build number
Integer
-
Factory use
99
Nominal L-N
voltage
Float
RMS Volts
100
Nominal L-L voltage
Float
RMS Volts
