lamp voltage for Flicker measurements according to IEC
61000-4-15.
Rotation_Convention_On_Vectors_Screen=
COUNTER_CLOCKWISE
The rotation convention used on the Vectors display screen.
NOTE: This tag does not affect measurements or rotation
errors. To fix rotation errors, swap any two phases in the
[Adjust_Phase_Connections] section.
CLOCKWISE
COUNTER_CLOCKWISE
Counter-clockwise:
Clockwise:
Minimum_Current_Display_In_Percent_Of_Rated_Current=0
A nonzero number here will cause any current reading to be
set to zero when it is less than the value specified here, as
well as the corresponding VA, Power,etc. for that phase.
The "Rated Current" in Amps is the value written on the
current module multiplied by any external CT ratio. 1% is a
recommended starting point if you want to use this feature.
