MULTIDOS
RS232 Interface
Application Constancy Check
14 D177.131.2/0
9 Application Constancy Check
Telegrams containing parameters alter a setting. If the parameter is omitted in the telegram, the actual setting is
returned. For clarification parameters are printed in
italic.
Example:
I0044 sets the interval time, I reads the actual interval time and is answered by I0044.
− If the unit is changed, the measurement is continued and the measuring values are re-calculated to the
new measuring unit.
− All telegrams that begin with X are only valid in XMODE. The XMODE is activated with XM1. If it is not ac-
tivated, you get E01 back as the telegram response.
It is only possible to select a set if the set is calibrated or if it is possible to calibrate the MULTIDOS or if the
MULTIDOS is in XMODE or if there is no calibrated set at all.
9.1 Basic Settings
Telegram Description Response
Ux Set/Read unit of measurement. Parameter x: 1 = Ampere, 2 = Gy/s, 3 =
Gy/min, 4 = Gy/h
Ux
Rx
Set/Read range settings. 1: Range Low, 2: Range High Rx
SETs Set/Read the calibration set to be applied. Parameter s: 1 up to 5
SETs
V Checking whether Gray or Röntgen, 0 : Gray
1 : Röntgen
Vx
XMx
x = 0: Switching of the extension mode
x = 1: Switching on the extension mode
XMx
XDx
Read/Set the display mode
0: normal, 1: omit the renewing of the display
XDx
