4 pulsar 3
EU – Certificate of conformity
Pulsar 3 is designed according to the general safety standards – especially home appliance’s standards,
such as EN 55014-1:2000 + A1:2001 + A2:2002 as well as EN 55014-2:1997 + A1:2001 (Cat.II)
ELPROG
ul. Przemysłowa 11
PL 35-105 Rzeszów
Features
1. Pulsar 3 charger
2. User’s manual
3. Connecting cable with alligator clips
4. SD memory card (containing PC software, user’s manual – PDF file)
5. USB cable
6. Temperature sensor
7. Optional BT antenna (only if the BT module is installed)
Definitions, abbreviations and symbols (in alphabetic order)
Battery types:
NiXX = NiCd (nickel-cadmium), NiMH (nickel-metal hybrid), NiZn (Nickel-Zinc)
LiXX = LiPo (lithium-ion polymer), Li-Ion (lithium-ion), LiFe (LiPh), (lithium-phosphate), LiHV (Lithium High
Voltage), LiS (lithium-sulphur)
Pb = lead battery (also lead-jelly)
Modes:
Charge = charging
Ch.Dis = charging and then discharging (a double process)
Condit = charging - discharging (capacity check) - charging to storage voltage
Disch. = discharging
Dis.Ch. = discharging and then charging (a double process)
Format = special formatting and NiXX package regeneration program
Store = special program used to prepare LiXX packages for longer storing
Test = special program for measurement of the internal resistance of battery pack (tested by discharge
impulse)
Parameters and abbreviations:
↑ = voltage change tendency marker; displayed In the menu window above „V” (Volt) during charging and
discharging, in the balancer window it marks the cell with the highest voltage.
↓ = voltage change tendency marker; displayed In the menu window above „V” (Volt) during charging and
discharging, in the balancer window it marks the cell with the lowest voltage.
Δ (with NiCd and NiMH) = Delta-Peak value; recognizing the charging state of NiCd and NiMH batteries
Δ (with LiXX and NiZn) = cell’s voltage difference In LiXX and NiZn packages
-,- Ah = limiter capacity settings
! = the exclamation mark informs of the altered parameter value as compared to the default settings (e.g. an
altered final charging voltage value)
Ah/c = equalized capacity per cell (in the balancer window)
Auto = automatic discharge current reduction; the current, after reaching a discharge voltage of the
package/cells, will be greatly reduced in order to reach a deeper discharge without exceeding the set voltage limit
B: = current balancer power
B ("B" („B” is displayed alternately with „V”) = additional balancing (in case the battery is still not correctly
balanced after end of charging process)
Beep = acoustic signal
BT = optional wireless communication
C = {Capacity} charged or discharged capacity
c = {Charging rate} charging or discharging current according to the battery capacity in Ah: Is displayed by current
justage when limiter is active
Config_(0-9) = Config_(0-9) = Writing (and reading) of the current configuration on SD card (incl. memory)
Contr. =display’s contrast settings
Cs = {Capacity supply} displays the amount of energy drawn from the power supply from the moment the charger
was plugged in
E = {End} displayed alternately with „V” when at the end of the process the current has been reduced
