Date
Setting the Date
џ Enter the 'Date' submenu with a short press of the Menu button (3). The date appears in
dd/mm/yyyy format.
џ To save your chosen date and exit the submenu, press and hold down the Menu button (3).
џ Set the required year, month and day with the UP (4) / DOWN (2) buttons. Press the Menu
button (3) to move through the digits.
Time
Setting the Time
џ Enter the 'Time' submenu with a short press of the Menu button (3).
џ Press the Menu button (3) to move to the hour setting.
џ Set the hour by pressing the UP (4) / DOWN (2) buttons.
џ To save your chosen time and exit the submenu, press and hold down the Menu button (3).
џ Select the time format (24-hour clock or AM/PM) by pressing the UP (4) / DOWN (2) buttons.
џ Press the Menu button (3) to move to the minute setting.
џ Set the minute by pressing the UP (4) / DOWN (2) buttons.
Units of
measure
M
Y
Selecting a unit of measure
џ Return to the submenu occurs automatically.
џ Enter the ‘Unit of measure' submenu with a short press of the Menu button (3).
џ Set the unit of measurement (metres or yards) by pressing the UP (4) / DOWN (2) buttons;
then press the Мenu button (3) .
M
Y
Default
Settings
џ Select the 'YES' option to reset to factory settings or 'NO' to cancel with the UP (4) / DOWN (2)
buttons.
џ If the YES option has been selected, the message 'Do you want to return to default settings?'
will appear together with options YES and NO. Select YES to format the memory card.
Note: When resetting to factory settings the date/time settings and the user pixel map are
saved.
џ If the NO option has been selected, formatting will be cancelled and the submenu will
reappear.
Restore Factory Settings
џ Enter the 'Default Settings' submenu with a short press of the Menu button (3).
The following settings will be restored to their factory state before being set by the user:
Operating mode – video. Mode – forest. Calibration mode – automatic. Language – English.
Wi-Fi – off (default password). Magnification – original value. PiP – off. Colour palette – White
Hot. Unit of measurement – metres.
џ Confirm your selection with a short press of the Menu button (3).
Formatting the
Memory Card
џ Confirm your selection with a short press of the Menu button (3).
џ If the NO option has been selected, formatting will be cancelled and the submenu will
reappear.
џ Enter the 'Memory Card Formatting' submenu with a short press of the Menu button (3).
This function enables the device's Flash Card (memory card) to be formatted (all files to be
deleted from its memory).
џ If the YES option has been selected, the message 'Format the Memory Card?' will appear
together with options 'YES' and 'NO'. Select YES to format the memory card.
џ The message 'Formatting memory card' means that formatting is in progress.
џ The message 'Formatting completed' means that formatting is completed.
џ Select the 'YES' option to reset to format the memory card or 'NO' to return to the submenu
with the UP (4) / DOWN (2) buttons.
Wi-Fi Settings
This option enables you to configure the device to operate on a Wi-Fi network.
џ Select the "Wi-Fi activation" option
Turn on/off Wi-Fi
џ Press and hold the Menu button (3) to enter the main menu.
џ A short press of the Menu button (3) switches Wi-Fi on/off.
Setting
a password
џ To save the password and exit the submenu, press and hold down the Menu button (3).
џ Set your desired password with the UP (4) / DOWN (2) buttons. The UP (4) button increases
the number and the DOWN (2) button reduces the numbers. Press the Menu button (3) to move
through the digits.
џ The default password (12345678) will appear on the screen.
This function enables you to set a password to access the device from an external device. This
password is used when linking an external device (e.g. a smartphone) to the device.
џ Press the Menu button (3) to enter the 'Wi-Fi settings' submenu.
Guest level. A Stream Vision user is able to view video footage from the device only in real
time.
Owner level. A Stream Vision user has full access to all the device's functions.
This sub-function enables you to configure the appropriate level of access to your device
made available to the Stream Vision app.
Setting
Access Levels
Removal of
Defective Pixels
When using the device, defective (broken) pixels may appear on the sensor: i.e. bright or dark
points of constant brightness that are visible on the image. AXION thermal imagers offer the
possibility of removing any defective pixels on the sensor programmatically, as well as to
cancel any deletion.
џ To save your choice and exit the submenu, press and hold down the Menu button (3).
Choose Language
џ Enter the 'Language' submenu with a short press of the Menu button (3).
џ Select one of the available interface languages (English, French, German, Spanish or
Russian) with the UP (4) / DOWN (2) buttons.
џ Confirm your selection with a short press of the Menu button (3).
PiP Mode
PIP
џ A short press of the Menu button (3) switches the mode on/off.
џ Press and hold the Menu button (3) to enter the menu.
џ Select the 'PiP Mode' option
Selection of the Picture in Picture Mode
PIP
Icon
brightness
џ Select the 'Icon Brightness' option.
џ A short press of the Menu button (3) confirms the selection.
џ Press and hold the Menu button (3) to enter the menu.
Adjusting icon brightness.
џ Select the brightness level of the pictograms with the UP (4) / DOWN (2) buttons.
џ A short press of the Menu button (3) opens the submenu.
General Settings .
This menu item allows you to program the following settings
Language
5
Microphone
This item allows you to enable (or disable) the microphone for recording sound during video
recording.
A short press of the Menu button (3) switches Microphone on/off.
џ Press and hold the Menu button (6) to enter the main menu.
џ Select the 'Microphone' option
Turning on/off the microphone
