Pulsar KRYPTON XG50 User Manual

3
USER MANUAL FOR KRYPTON XG50 THERMAL IMAGING MONOCULAR
ENGLISH
TECHNICAL SPECIFICATIONS
MODEL KRYPTON XG50
SKU 77375
Microbolometer
Type Uncooled
Resolution, Pixels 640x480
Pixel Pitch, µm 12
Frame Rate, Hz 50
Optical characteristics
Monocular magnication, x 5
Recommended daylight optics magnication, x 1.5-6
Lens F50/ 1.2
Digital Zoom, x -
Eye Relief, mm 18
Eye Relief Diameter, mm 6
Field-of-view (Horizontal), deg/m per 100 m 8.7 / 15.4
Eyepiece Focusing Range, Diopter +5/-5
Detection Range (Animal Height 1.7 m), m/y 2300/2515
Minimum Focusing Distance, m 5
Display
Type AMOLED
Resolution, Pixels 960x720
Operational characteristics
Power Supply, V 3-4.2
Battery type Li-Ion Battery Pack IPS 7
Capacity 6400 mAh
Rated Output Voltage DC 3.7 V
External Power Supply 5 V (USB)
Max. Battery Pack Life (at t = 22 °C), hours* 8
Operating temperature, °C -25 … +50
Overall Dimensions, mm/inch 260x93x76 / 10.24х3.66х2.99
Weight (without battery and monocular), kg/oz 0.52 / 18.34
Video recorder
Photo/Video Resolution, Pixels 960x720
Video/Photo Format .mp4/.jpg
Built-in Memory 16 GB
Wi-Fi channel
Frequency 2.4 GHz
Standard 802.11 b/g
Line-of-Sight Reception Range, m** up to 15
* Actual operating time will depend to what extent the Wi-Fi and built-in video recorder is used.
**The reception range may vary depending on various factors: obstacles, other Wi-Fi networks.
PACKAGE CONTENTS
•
KRYPTON XG50
•
Power Adapter
•
Pulsar 5x30 B Monocular
•
USB Cable
•
Carrying Case
•
Quick Start Guide
•
IPS7 Battery Pack
•
Lens-Cleaning Cloth
•
Battery Pack Charger
•
Warranty Card
DESCRIPTION
The KRYPTON XG50 thermal imager is designed for a variety of applications, including hunting surveillance,
security activities, day and night photo and video shooting. The KRYPTON XG50 thermal imaging module can be
mounted (using the correct Ring Adapter) on to the objective lens housing of various daylight optical devices,
converting them into a highly-sensitive thermal imaging device.
FEATURES
•
High resolution thermal imaging microbolometer
•
Microbolometer pixel size of 12 microns
•
High-resolution AMOLED display
•
Easily converts daylight optical devices into thermal imaging devices
•
Preserves the benets of daylight optics in night-time conditions
•
Three calibration modes (manual, semi-automatic and automatic)
•
Four observation modes: Forest, Rocks, Identication, User
•
Compatible with a wide range of daylight optical magnications
•
Detection distance up to 2300 m
•
Instant start
•
Display off function
•
Built-in video recording
•
Remote rmware update
•
Fully watertight (IPX7 protection class)
•
Wide operating temperature range (-25 °С – +50°С)
VIDEO/AUDIO RECORDING
•
Built-in video recorder
•
Integration with iOS and Android devices
•
Wi-Fi Smartphone remote control and surveillance
•
YouTube Live broadcasting and direct recording on the Internet via a smartphone and the Stream Vision app.
BATTERY PACK
•
Quick-change IPS7 Li-ion battery pack
•
USB charging option

Pulsar KRYPTON XG50 Specifications

General

Objective Lens	F50/1.2
Battery Life	8 h
Protection Degree	IPX7
Battery Type	Li-Ion Battery Pack APS5
Video / Photo Resolution	1024x768
Video / Photo Format	.mp4 / .jpg
Built-in Memory	16 GB
Wi-Fi Channel	2.4 GHz
Objective Lens Diameter	50 mm
Exit Pupil	5 mm
Eye Relief	15 mm
Recognition Range	800 m
Detection Range	2300 m
Display	AMOLED
Operating Temperature Range	-25 … +50 °C
