OPERA
TION
13
• To avoid recoil, pull starter cord slowly until resistance is felt, then pull rapidly.
WARNING!
Pull cord recoils rapidly and pulls arm towards engine faster than you can let go which
could result in injury.
• Always start the engine and let it stabilize before connecting any electronic devices.
• Disconnect all electronic devices before stopping the engine.
WARNING!
Never start or stop engine with electrical devices plugged in to the receptacles. Failure to
do so could damage the generator and / or connected electrical devices.
Receptacles and Extension Cords
Only use high quality, well-insulated, grounded extension cords in good condition with generator receptacles. Follow each
load manufacturer’s power rating recommendation when selecting receptacle and extension cord.
This generator is equipped with the following receptacles:
How to Stop Engine (See fig 13-16))
• All loads MUST be disconnected from the generator. Never start or stop the engine with electrical devices plugged in to
the receptacles. (See fig 13)
W
hen using gasoline
1.Turn the engine ON/OFF switch to the “OFF” position. (See fig 16)
2.Turn the fuel valve lever back to the OFF position.(See fig 14)
When using LPG
1.Turn the engine ON/OFF switch to the “OFF” position. (See fig 16)
2.Close supply valve on LPG bottle. (See fig 15)
Fig 13 Fig 14 Fig 15
Fig 16
• Two 120 GFCI Outlets (NEMA5-20).
• One 120 Volt AC, 30 Amp RV receptacle (TT-30R).
• One 120 / 240 Volt AC, 30 Amp twist lock receptacle (NEMA L14-30R).
120 Volt GFCI duplex receptacles (NEMA 5-20R)
• This receptacle has a 20 Amp push-to reset circuit breaker to protect against overload.
• Each socket is rated to operate 120 Volt, AC, single phase, 60Hz loads requiring up to 2400 watts (2.4 kW) at 20
Amps.
• Use extension cords having a minimum rating of 125 Volts AC, 20 Amps.
ON
OFF
