Pulsar PG6580BCO - Assembly - Unpacking and Parts; Unpacking the Generator; Packing List Verification

8
ASSEMB
L
Y
Unpacking
1. Place box on a level surface.
2. Remove all items from box except the generator. Make sure all items listed on the packing list are included and not
damaged.
3. Cut down the sides of box being careful to avoid hitting the generator.
4. Leave generator on box to install wheel assembly.
Packing List
Check all loose parts to the following list. Contact your dealer if any loose parts are not included.
Description Qty
Handle Assembly
Bolt
Nut
2
2
4
Wheel Assembly
2
Hair pin
2
Axles
2
Description Qty
Generator
1
Operator’s manual
1
Product registration card
1
Toolkit
Spark Plug Wrench
1
1
Washer
2
Description Qty
Foot Assembly
Bolt
2
4
Funnel
++ + + + +
+ ++ +
( )
++
Handle Assembly Wheel Assembly
+
Foot Assembly
2
Bushings (Flanged)
+
Engine oil
1
Two-stage regulator
1
OIL
+
+
Measuring Cup 1
