Puratech 5100 - Service Settings: Configuration Chart; Mode and Salt Setting Guidance

PuraTech
®
Owner’s Manual 12/11/2013 18
Service Settings, Cont.
Mode 1 (Timer Mode) and Mode 2 (Demand Delayed Mode) Setting Chart
This section provides guidance for using different Service Settings to achieve the desired capacity.
PuraTech
Model 5100
Mode 1 and Mode 2
Yes
Regeneration Frequency
Mode 1 only
96 hour regeneration (if iron present—yes)
1
Yes or No
#1 Salt Setting
Backwash 1 (minutes)
01.0
Brine/Rinse (minutes)
19.5
Backwash 2 (minutes)
03.0
Capacity–grains @ salt–lb (grams @ salt–kg)
5,500 @ 1 lb (356 @ 0.5 kg)
#2 Salt Setting
Backwash 1 (minutes)
01.0
Brine/Rinse (minutes)
22.0
Backwash 2 (minutes)
03.0
Capacity–grains @ salt–lb (grams @ salt–kg)
13,700 @ 3 lb (887 @ 1.4 kg)
#3 Salt Setting
2
Backwash 1 (minutes)
01.0
Brine/Rinse (minutes)
26.0
Backwash 2 (minutes)
03.0
Capacity–grains @ salt–lb (grams @ salt–kg)
23,700 @ 6 lb (1535 @ 2.7 kg)
#4 Salt Setting
2,3
Backwash 1 (minutes)
01.0
Brine/Rinse (minutes)
30.0
Backwash 2 (minutes)
03.0
Capacity–grains @ salt–lb (grams @ salt–kg)
30,800 @ 9 lb (1995 @ 4.1 kg)
1
If iron is present in water supply, use salt setting #3 or #4.
2
If iron is present in the water supply, set Backwash 1 to 7 minutes.
3
Do not use this salt setting in California.
