20) Dynamic/static illustration of the process, graphics zoom in / out, dynamically tracking cut-off point under zooming state.
21) Automatically memorize the working situation and the last cutting point when power off.
22) «Cutting offset» function can avoid waste the steel plate when the nesting of the plate is calculated wrong.
23) Set up different administration authority and the corresponding password to safeguard the interests of managers.
TECHNICAL STANDARD
1) Control Axis: 2
2) Control accuracy: +/-0.001mm
3) Coordinate range: +/- 99999.999mm
4) Max pulses : 200kHz Max speed: 15000 mm/m
5) Max lines of code: 150000 lines
6) Max size of single code file: 4M
7) Time resolution: 10ms
8) Working Voltage: DC 24V in put
9) Working Temperature: -10 — 60 °C. Relative Humidity, 0-95%.
SYSTEM INTERFACE
1) 15 pins interface of 2 axis of motor drive.
2) 25 pins interface of 16 channels optical couple output ports, max back flow current 300mA.
3) 25 pins interface of 16 channels optical couple input ports, max output current 300mA.
4) USB interface on the front panel.
5) Extend IO input/output ports, PWM input ports, analog input ports.
HARDWARE CONFIGURATION
1) Monitor:15 inch, 1024*768, high definition 16 million colors and high brightness LCD or 10.4 inch 800*600, 26 million color LCD.
2) Memory: 64M SDRAM.
3) Memory available for user: 256M or 1G electronic hard disk.
4) System master frequency: 400MHz.
5) USB: USB 1.1 front interface.
6) Keyboard: electronic PCB foil keyboard (one machine) or standard industrial keyboard (split type machine).
7) Chassis: full-steel structure completely shielded which defends electromagnetic radiation, interference and static electricity.
