Purelogic HYD-2300

HYD-2100. CNC Plasma&Flame Cutting Control System
Edition of 28.07.2015
47
www.purelogic.ru8 (800) 555 63 74
8421 code (DCBA)
0001
0101
1101
0011
1011
1001
0111
1111
0000
0010
1010
0110
1110
0100
1100
1000
No Input0
Decimal
Go back according to the original track
Move forward vertically
Ignite Input
Raise the cutting torch
Left lateral movement
Cutting torch
Slow down
Start
Accelerate
2
10
6
14
4
12
8
1
5
13
3
11
9
7
15
Function
Turn on or off the cutting oxygen
Move forward according to the original track
Pause
Start
Move toward right horizontally
Move for the negative direction vertically
8421-type remote control input is designed by the user, the user can also use the company’s wireless remote control module.
INPUT CONFIGURATION
The number and type of input port can be reconfigured. For example, the right input port can be Pin 1, also can be configured to Pin 7, input type can be
normally open type, can also be normally close type. Configuration methods are shown in Fig. 59.
Press F5 (Diagnosis), F8 (SystemDef), F3 (Define), enter the password «1396» and press ENTER in turn on the main Interface.
