Purelogic HYD-2300

HYD-2100. CNC Plasma&Flame Cutting Control System
Edition of 28.07.2015
45
www.purelogic.ru8 (800) 555 63 74
Signal name
X- limit
Arcing successfully
Y- limit
Move right/D
Plasma collision
X+ limit
Y+ limit
Positioning successfully
Emergency stop
Move left/C
X+ stop input, float it if not use, this is horizontal1
Pin number
Y+ stop input, float it if not use, this is vertical
Emergency stop input, float if not use
Remote control input
2
5
3
7
14
4
15
8
6
Remark
X- stop input, float it if not use, this is horizontal
Y- stop input, float it if not use, this is vertical
Remote control input
