USR-DR13X User Manual
Figure 13. Current status
The function of the device status part is to display some specific information of the current device, including
module name, IP address, MAC address, etc.
Table 6. Description of Current status
The name of the serial server, which can be customized by the user on the "Miscellaneous
settings" page.
The IP address of the serial server.
The identification code of the device.
The MAC address of the serial server.
IP：The IP of remote host, it displayed once the TCP connection is established,
Tx: The data count from serial to network
Rx: The data count from network to serial
When the TCO232-30X work in TCP server mode, the page can display up to 5 connection
information.
