PV Powered PVP4800 - Table 4-5 Conductor Use by Inverter Model

22
Model
AC Line Input
Terminal
Conductor Type
PVP1100
L1 L1 or L2 of 120VAC Split Phase Service
L2 Neutral of 120VAC Split Phase Service
PVP2000
L1 L1 of 240VAC: 120VAC Split Phase Service
L2 L2 of 240VAC: 120VAC Split Phase Service
PVP2500
L1 L1 of 240VAC: 120VAC Split Phase Service
L2 L2 of 240VAC: 120VAC Split Phase Service
PVP2800
L1
Phase A, B or C of 208VAC: 120V Wye
Three Phase Service
L2
Phase A, B or C of 208VAC: 120V Wye
Three Phase Service
PVP3000
L1 L1 of 240VAC: 120VAC Split Phase Service
L2 L2 of 240VAC: 120VAC Split Phase Service
PVP3500
L1 L1 of 240VAC: 120VAC Split Phase Service
L2 L2 of 240VAC: 120VAC Split Phase Service
PVP4600
L1
Phase A, B or C of 208VAC: 120V Wye
Three Phase Service
L2
Phase A, B or C of 208VAC: 120V Wye
Three Phase Service
PVP4800
L1 L1 of 240VAC: 120VAC Split Phase Service
L2 L2 of 240VAC: 120VAC Split Phase Service
PVP5200
L1 L1 of 240VAC: 120VAC Split Phase Service
L2 L2 of 240VAC: 120VAC Split Phase Service
Table 4-5 Conductor Use By Inverter Model
A neutral conductor is used only by the PVP1100. A neutral conductor is
not used by any other inverter model. A ground conductor is used in all
congurations.
NOTE: ToavoidanincreaseinACvoltagelevel,whichmayleadto
nuisancefaults,PVPoweredrecommendssizingtheconductor
foradropoflessthan2%.
