A.3 Circuit Breaker Requirements
Inverter Model Circuit Breaker Required
PVP1100 1 pole 15A
PVP2000 2 pole 15A
PVP2500 2 pole 20A
PVP2800 2 pole 20A
PVP3000 2 pole 20A
PVP3500 2 pole 20A
PVP4600 2 pole 30A
PVP4800 2 pole 30A
PVP5200 2 pole 30A
Table A-3 Circuit Breaker Requirements
A.4 Abnormal Specifications
The specications listed below are classied as abnormal and are not
representative of normal operation.
Abnormal Specications PVP1100 PVP2000 PVP2500 PVP2800
Momentary current transient
obtained during abnormal operation
100 A-pk /
0.58 ms
142 A-pk /
0.66 ms
88 A-pk
166 A-pk /
0.61 ms
Maximum input source backfeed
current to input source
0A
Abnormal Specications PVP3000 PVP3500 PVP4600 PVP4800 PVP5200
Momentary current transient
obtained during abnormal operation
166 A-pk /
0.61 ms
88 A-pk 88 A-pk 88 A-pk 88 A-pk
Maximum input source backfeed
current to input source
0A
Table A-4 Abnormal Specifications
