Appendix A - Specifications
The specications detailed below are expected operational parameters, and
should be used in designing your PV system in accordance with the NEC.
A.1 Inverter Specifications
Specications PVP1100 PVP2000 PVP2500 PVP2800
Maximum DC Input Voltage (VOC) 500VDC
DC Voltage Operating Range (V)
115VDC-
450VDC
115VDC-
450VDC
140VDC-
450VDC
180VDC-
450VDC
DC MPPT Range (V)
115VDC-
380VDC
115VDC-
380VDC
140VDC-
380VDC
180VDC-
380VDC
DC Imp Maximum Current (A) 10A 18A 20A 18A
DC Isc Maximum Current (A) 26A
AC Operating Range (V)
105.6V-
132.5V
211V-
264V
211V-
264V
183V-
229V
AC Frequency Range (Hz) 59.3Hz-60.5Hz
AC Nominal Voltage (V) 120V 240V 240V 208V
Normal Output Frequency 60Hz
Synchronization in Rush Current < 2.0A 8.4A < 2.0A
Power Factor 0.99 - 1.0 at > 50% Power
AC Maximum Continuous Current (A) 10A 9A 11A 13A
Continuous Output Power (Watts) 1100 2000 2500 2800
Maximum Continuous Output Power
(Watts)
1100 2000 2500 2800
Enclosure Steel- NEMA 3R to UL 50 Standards
Dimensions (H x W x D)
With AC/DC Disconnect (H x W x D)
22 1/2” x 15 5/8” x 8 1/4”
(57.15cm x 39.69cm x 21cm)
30 3/8” x 15 5/8” x 8 1/4”
(77cm x 39.69cm x 21cm)
Weight (lbs) 84.5 (38 kg) 92.5 (42 kg) 106.5 (48 kg) 106.5 (48 kg)
Cooling Natural Convection - Heat Sink
Relative Humidity 0% to 95% Condensing
Ambient Temperature Range -15°F to 105°F (-25°C to 40°C)
Environmental Rating NEMA 3R
Listings
UL 1741, IEEE 1547, IEEE 519, IEEE 929, IEEE 620,
CSA 22.2 107.1
GFI Fuse Littlefuse KLKD1 1A/600VDC
Table A-1 Inverter PVP1100 through PVP2800 Specifications
