www.PyleUSA.com
11
1. TUNER ANT: Connect for AM and FM antennas.
2. A SPEAKER OUTPUT TERMINALS: Connect your speaker system to these
terminals.
3. B SPEAKER OUTPUT TERMINALS: Connect your other speaker system(s) to
these terminals.
4. COOLING FAN
5.6. R/L OUTPUT
7.9. DIGITALAUDIO OUTPUT: One coaxial one optical, this output can connect to
the amplier with dolby digital or DTS decoder to play the movie with
correspondent records.
8.10.11.12.13. VIDEO OUTPUT, S-VIDEO OUTPUT, COMPONENT VIDEO OUTPUT
Press the “relevant” key on remote control to choose the output mode.
14. AUDIO INPUT JACKS: Connect the audio ouput jacks of MP3, AUX to these jacks.
15. SUB-WOOFER OUTPUT JACKS 1&2
16. COOLING FAN
17. 120V/240V SWITCH: According to power voltage, push this button to the
station of the 120V or 240V.
18. POWER CORD: Connect to AC 120V/60Hz & 240V/50Hz outlet.
REMOTE DEVICE FUNCTION
Remote Control Operation
1. Remote control should be operated within 6 meter and the scope of 30° in front
of receiver.
2. Make sure that there is no big obstacle between remote control and machine.
3. Remote sensor should be far away from the light. High amounts of light can
aect its performance.
