Figure 8.7
Set the pilot lamp mode, to one of the following three options:
(1) Non-connected network out: Blinks while connected to the internet and turn off when disconnected.
(2) Non-connected network with more slow-frequency flicker: Blinks while connect to the internet and
more slower when disconnected.
(3) Extinguished: Stays OFF.
3.15 Backup & Restore
Figure 8.8
1
）
Backup: Backup all the IP Camera Parameters, if you want to save all the current settings that you have set
already, you can click Submit, then all the parameters you set will be stored as a parameters bin file.
2
）
Restore: Restore all the IP Camera Parameters, if you want to change the camera’s settings to a certain
status which has a backup, click Browse to load the bin file, then Submit it.
Log
Figure 8.9
Record User information, including weekday, date, time, user name, visitor IP address etc.
