-18-
Basic Operation
Balance:
Fader:
R0-10toL0-10.
Adjust sound balance between left
and right speakers by using VOL + / -
F0 10toR0-10.
Adjust sound balance between front and
rear speakers by using VOL + / VOL - .
.
-
The button is to be activated for
the following reasons:
A. Initial installation of the unit when
all wiring is completed.
B. All the function buttons do not operate.
C. Error symbol on the display.
RESET
Touch the screen the DSP range
(orpresstheEQbuttononthe
remote control ) to select one of
the preset sound modes .
The information will display in the
monitor as follow :
(Rock/Pop/Jazz/Classic/Flat) .
Setting Audio Modes
It`s depend on your habit to select the
Audio mode .
POP
FLAT
ROCK
CLASSIC
JAZZ
DSP
touch to select
GOTO
S-WOOFER
DSP
OSD
FLAT
DISC-IN
16: 18
POP
TA AF CLK LUD
Reset Factory Settings
RESET button is placed on the housing
and must be activated with either a
ballpoint pen or thin metal object.
RESET
RES
ALTERNATE AUDIO/VIDEO SOURCE
On the front panel of the unit , there is an
AUX IN jack, to connect analogue replay
devices. Use this jack to replay sound of
other replay equipment such as
DVD players, computers, etc.
Via the loudspeakers.
1). Please f
connect the external device with stereo
jack plug the AUX IN socket .
2). Press the MOD button to select the
AUX IN connection.
3). Use the buttons on the external
device itself to operate it .
ollowing the diagram below,
Headphones port
AUX IN
AUX IN
