-14-
Unit Keys :
Control Panel
1 AUX Input JACK
For information about connecting a AUX device, please see page 25 .
2 IR SENSOR
3 VOL+/VOL- KNOB
In normal mode, this knob is used to increase or decrease the volume. It is also
used as an UP/DOWN knob when audio or video settings are being adjusted
when accessed using the SELECT button.
4 (POWER On/Off )/MODE BUTTON
Press this button to switch the device on. WELCOME appears in the display.
Press it again to switch the device off. SEE YOU appears in the display.
In playback mode, you can use the button to select the input mode by pressing
repeatedly until the proper one is found :
DISC > AUX IN > RADIO .
5 ANGLE (Screen position)
Press this button repeatedly to cycle through the different positions.
12
9
8
7
5
4
10
11
6
1
2
3
RES
SEL
CH1-6
REL
MOD
VOL
IR
AUX IN
CAR DVD/VCD/CD/MP3 PLAYER WITH MPEG4
TOUCH SCREEN
