Pyle PLMRA220 - Stereo Input Connections

www.PyleUSA.com10
Electrical Connections
PLMRA420
Stereo Input Connections
PLMRA220
Using Low Level Inputs
Using High-Level Inputs
Head Unit
Turn ON remote
+12V
12V battery
Head Unit
L/R Audio Outputs
from speaker terminals Wiring harness
Head Unit
PLEASE NOTE:
If using high-level inputs, do not use the
low-level RCA inputs at the same time.
