High Pass Frequency Control: When the crossover selector switch is in "HIGH-
PASS" mode, this control sets the lower frequency limit for the audio program
sent to the speakers.
Bass Boost Level Control: This control permits adjustment of the bass level up
to an increase of approximately 18 dB.
Low-Level Inputs: This amp features gold-plated RCA input jacks for high
impedance input. Use these with car stereo outputs that utilize RCA-type
connector cables.
High-Level Inputs: If your car stereo lacks RCA-type output jacks, you may
connect the speaker output leads to these input connectors.
Power LED: This indicator lights up when power is applied.
Protection LED: This indicator lights up when the built-in protection circuitry is
activated.
Power Fuse: The fuse protects the amplier and your car's electrical system
from short circuits.
Power Terminals: Use these connectors to deliver power, ground, and remote
turn-on control to the amplier.
Speaker Connections: These terminals are 14K gold-plated to guarantee high
conductivity and minimize signal loss.
Technical Specications
Output Power @ 14.4V DC, 1KHz:
• RMS Power @ 4 Ohms: 40 Watts x 2
• RMS Power @ 2 Ohms: 70 Watts x 2
• Maximum Power Output: 300 Watts x 2
Frequency Response: 15 Hz - 30 KHz
Input Impedance:
• Low-Level Inputs: 10K Ohms
• High-Level Inputs: 100 Ohms
