Features and Controls
PLMRA220 - 2 Channel Amplier
Control Functions
Crossover Mode Selector: When used with normal full-range systems, set this
switch to "FULL." If you wish to use the internal crossover to power a driver of a
specic frequency range, use the "LOWPASS" or "HIGHPASS" settings.
Input Level Control: Use this control to match the output of your head unit to
the amplier. Start with your head unit set at about the 2 o'clock position,
increase the amp level control until distortion begins, and then reduce slightly.
Low Pass Frequency Control: When the crossover selector switch is in "LOW
PASS" mode, this control sets the upper frequency limit for the audio program
sent to the speakers.
Speaker Connections
Power Fuse
Power Terminals
Power LED
Protection LED
High-Level Inputs
Low-Level Inputs
Input Level Control
Crossover Mode Selector
Bass Boost Level
High Pass Frequency Control
Low Pass Frequency Control
