APPENDIX A: FAULTS
Device Codes
If a device on the PCX system is not installed correctly or has lost its communication with the
panel, “DEVICE FAIL” will be shown on the LCD keypad followed by a 3-figure device code. The
first digit identifies each type of device:
1 = End Station
2 = Keypad
3 = Tag Reader / Door Station / RIX2
4 = Remote Input Expander
5 = Remote Output Expander
The digits after refer to that devices address, for example:
DEVICE FAIL 401 = means that the Remote Input Expander addressed as “01” has a problem.
Fault Indications
COMMUNICATION FAULTS
Fault Description Solution
MODEM
FAULT
End Station unable to
communicate with Digi
Modem
If modem not present, ensure that “Disable Digi”
option is set to ‘YES’ and “DOWNLOAD MODE” is
set to ‘NONE’ or ‘RS232’.
If present, but not detected, check Digi Modem is
inserted correctly and complete initialisation by
pressing End Station ‘RESET’ button for 2
seconds.
DIGI FAIL
COMM
Call to ARC from Digi
Modem DigiModem has
failed.
Note: This is a
communication problem,
which is rarely caused by
an equipment fault.
Check ALL call details are programmed correctly.
Ensure signalling format is correctly set for ARC
receiver.
If only one call number programmed, ensure
“STOP ON SUCCESS” = ‘YES’ and “TRY SAME”
is selected – NOT “TRY NEXT”.
PHC TEST
FAIL
Unable to communicate
with Pyronix Host
Computer.
Note: This would also
result if the telephone line
had premium rate calls
blocked.
Ensure Digi is enabled, and at least one SMS call
is correctly programmed.
Check that ordinary phone on same line connects
to PHC and modem tones heard - if not, problem is
PSTN – NOT equipment.
De-program SMS content types for each call, exit
Engineer menu, press RESTART button, and retry
PHC test from Manager menu.
LINE FAULT
100
PSTN Line Fault signalled
by Digi Modem.
Only operative if "DOWNLOAD BY MODEM"
selected OR "DISABLE DIGI/SMS" is set to 'NO'
Note: 'Line Fault' timer operative.
ATE LINE
FAULT
PSTN Line Fault signalled
by device using STU/ATE
pins on End Station.
Only operative if Site Option "DIGIREPLY" is set to
'STU' or 'Digicom.'
Note: 'Line Fault' timer operative
ATE FAIL
COMM
Call to ARC from device
using End Station STU/ATE
Only operative if Site Option "DIGIREPLY" is set to
'Digicom.'
