Pyronix PCX 46 Engineer Reference Manual

PCX 46 Programming Reference
Page: 14
No. Output Type Active Restore
0000 Not Used
0001 Fire At fire alarm activation When a valid code is entered
0002 PA Any At personal attack activation When a valid code is entered
0003 Burglary Any At burglary alarm from any area At first valid code entry
0004 Final Arm All When ALL areas are armed At code entry to disarm
0005 Open After Alarm
(Abort)
When system is silenced after ‘burglary’
alarm has been activated
After 2 minutes
0007 Tamper Any Tamper alarm in any area At code entry to silence
0008 Duress Any At a Duress alarm in any area When a valid code is entered
0009 PA Device Any At alarm on a PA input only from any
area. (This does not include the keypad
PA)
When a valid code is entered
0010 Gas At gas alarm When a valid code is entered
0011 Arm Fail Pre-set time after start of exit time, if
exit procedure is not complete
At code entry to rearm
0012 Entry Deviation When deviation from entry route occurs,
during entry time
At code entry to disarm
0013 System Ready Any When any of the inputs but the Entry
Delay and Follow are closed
If fault exists, and after final arm
0014 Bell Any After alarm in any area When alarm silenced or when siren
timer expires
0016 Strobe Any After alarm in any area When disarmed or when strobe timer
expires
0017 Bypass Rearm Any When inputs are bypassed at rearm in
any area. Turned on after 1st alarm if
active when rearmed
When system disarmed
0018 Burglary Any At Burglary alarm in any area At code entry to silence
0019 Ready All When all inputs but the Entry Delay and
Follow are closed
If fault exists, and after final arm
0020 Exit Starts All At start of exit time to arm LAST area At disarm FIRST area (i.e. no longer
fully armed)
0021 Exit Starts Any When exit time starts to arm FIRST area At code entry to disarm LAST area
0022 Final Arm Any When ANY area has been armed At code entry to disarm LAST area
0023 Strobe if Arm Fail Works similar to output 016, but also fires if the arm fail timer expires.
0024 Unable to Arm This output turns on for 5 seconds when the system is disarmed via a keyswitch
input (either pulsed or latched keyswitch)*
0025 Keyswitch Disarm Output activates when an arming procedure is completed with inputs bypassed.
0026 Arm with Bypass Active when the system is armed with an input bypassed.
0027 Pulsed Burglary Any Active when burglary alarm is triggered, but deactivates once the Pulsed
Intruder timer has expired (see Program Timers).
0028 Power Fault Active during low volts and battery faults. Restores at code entry after fault
cleared.
0031 Entry Active during any Entry time
0032 Exit Active during any Exit time
0033 Entry / Exit Active during any entry or exit time
0034 Lights When exit or entry timer starts 20 seconds after arm/disarm
procedure completed
0035 Follow Input Active when a specific input number has been activated. It allows the following
options to be programmed:
Follow Type (Follow, Timed, Latched, Code Reset);
Follow What (Input, Shunt List, Sub-Area, Area);
Follow When (Always, When Armed, When Disarmed);
Input to Follow (between 1 to 64)
0036 Shunt Fault This input activates if someone tries to shunt an input group where some of the
inputs allocated to this group are open.
0037 Restore 1 At code entry to arm. The normal state
of this input is 0v and it changes to 12v
when activated.
After 3 seconds
0038 Restore 2 Activates whenever an additional area is
armed. The normal state of this input is
0v and it changes to 12v when activated.
When disarmed
0039 PIR Latch 1 When armed (and in Walk Test) At alarm, or when disarmed
0040 PIR Latch 2 This is the inverse polarity to
PIR Latch 1
At alarm, or when disarmed
