PCX 46 Programming Reference
Page: 33
Send Event to PC 1, 2, 3 or 4
Events can be sent from the panel to up to 4 remote PCs running UDL software. This option allows the
choice of which PC to send the events to.
PC 1, 2, 3 or 4 -> Modem Telephone Number
Enter the telephone number to which the PC modem is connected. Press a button to add any
symbols: ‘,’ = 2 second pause, ‘+’ for roaming calls.
Send Alarms
If enabled, the panel will report ‘alarm’ events to the PC running UDL software.
Send Faults
If enabled, the panel will report any ‘fault’ events to the PC running UDL software.
Send Open / Close
If enabled, the panel will report ‘open/close’ (arm/disarm) events to the PC running UDL software.
Send Access Control
If enabled, the PCX 46 will report any ‘access control’ events to the PC running UDL software.
UDL Password
This password is used to identify the UDL connection. Make sure the password here and on the PC
InSite software are the same.
Redials:
The number of redials that it will call to the InSite software before it fails.
5.22 PC Connect Menu?
The PC Connect Menu can be used by the engineer to make the panel to dial to a remote PC where the
UDL software is installed (rather than the PC dialing the control panel). This menu is also available from
the Master Manager menu to enable them to activate a connection from user mode.
Select PC to Dial
Select PC 1 to 4. The telephone number of the PC modem/s (1 to 4) should be pre-programmed in
‘Options Up / Downloading’ menu.
Select PC to Dial
Select Operation
The following actions can be performed: Connect to PC – If the customer has not been created in UDL
software it will take the data automatically from panel and create customer. If the customer has been
created in the UDL the panel will connect to this customer database.
Test Call
Send test call to the ARC.
RM Service – Will force RM Service report for the last 6 months.
Data from PC, Data to PC – Up/Down loading info from/to UDL.
Diagnostics – Forces full panel diagnostic test and sends it to UDL setting new service date.
Commissioning – Just sets a date when the system is going to be used from. NOTE: There is a
shortcut to connect to ‘PC number 1’ from when the panel is in disarmed mode. To activate such a call
from the keypad, press a followed by 5555. The display will not change but PCX 46 will dial the first
PC programmed in ‘Options Up / Downloading ‘ automatically.
5.23 Software Revision?
This option shows the software version and hub version installed in the panel. Please obtain the software
version number prior to contacting customer support so that the correct information can be given upon
supporting the product.
