PCX 46 Programming Reference
Page: 17
Access Control
Allows the reader to control doors fitted with electrical locks. On the readers there are 2 inputs that
also can be outputs. They can be connected to the lock for opening and controlling the door.
Lock Open Time: This is the time the door release is going to be active when a valid tag is presented.
Door Open Time: This is the time the door is allowed to be open before triggering an alarm.
Door Name: Enter the name of the door such as Front Door.
Door Location: Enter the location of the door such as First Floor.
NOTE: Access control falls outside the scope of EN50131-1
Disarm Only
Allows the reader to be used to disarm the system only.
Device Disarms: This feature programs which area(s) the reader can disarm.
Device in Area: This feature programs in which area(s) the reader is active.
Device Name: Enter the name of the door such as Front Door.
Device Location: Enter the location of the door such as First Floor.
Entry Control
Allows the reader to be used as arm/disarm Device and access control.
Device Arms Areas: This feature programs which area(s) the reader can arm.
Device Disarms: This feature programs which area(s) the reader can disarm.
Device in Area: This feature programs in which area(s) the reader is active.
Lock Open Time: This is the time the door release is going to be active when a valid tag is presented.
Door Open Time: This is the time the door is allowed to be open before triggering an alarm.
Door Name: Enter the name of the door such as Front Door.
Door Location: Enter the location of the door such as First Floor.
Keypad Device Type
Device Arms Areas: This feature programs which area(s) the keypad can arm.
Device Disarms: This feature programs which area(s) the keypad can disarm.
Device in Area: This feature programs in which area(s) the keypad is active.
Door Name: Enter the name of the door such as Front Door.
Door Location: Enter the location of the door such as First Floor.
