Page #40 background image
AWARD BIOS Description
3 - 8
Chipset Features Setup
ROM PCI/ISA BIOS (2A69JQ1D)
CHIPSET FEATURES SETUP
AWARD SOFTWARE, INC.
Auto Configuration : Enabled SDRAM CAS latency Time : 3
DRAM Speed Selection : 60ns
MA Wait State : Slow
EDO RAS # TO CAS# Delay : 3
EDO RAS # Precharge Time : 3
EDO DRAM Read Burst : X333
EDO DRAM Write Burst : X222
DRAM ECC Select : Disabled
CPU- TO -PCI IDE POSTING : Enabled
System BIOS Cacheable : Disabled
Video BIOS Cacheable : Disabled
Video RAM Cacheable : Disabled
8 bit I/ O Recovery Time : 1
16 bit I/ O Recovery Time : 1
Memory Hole At 15M-16M : Disabled
Delayed Transcation : Enabled
ESC: Quit ↑↓→←: Select Item
AGP Aperture Size (MB) : 64 F1: Help PU/PD/+/- : Modify
SDRAM RAS- to - CAS Delay : Slow F5: Old Values (Shift)F2: Color
SDRAM RAS Precharge Time : Slow F7: Load Setup Defaults
Figure-5 Chipset Features Setup Menu
The following pages tell you the options of each item and describe the
meaning of each option.
Item Option Description
Auto Configuration
Enabled
Automatically configure DRAM Timing
according to the value of “DRAM Speed
Disabled
Manually configure.
Note: It is recommended to choose
“Enabled” option for common users.
DRAM Speed
50ns,
This item is of selected EDO DRAM read/write
timing. You must ensure that your DIMMs are as fast
