AWARD BIOS Description
3 - 18
+3.3V Voltage : 3.32V
VTT (+1.5V) Voltage : 1.53V`
+5V Voltage : 5.02V
VCCVID (CPU) Voltage : 2.81V
+12V Voltage : 11.96V
-12V Voltage : -12.03V
-5V Voltage : -6.37
Chassis status : Closed
ESC: QUIT ↑↓→← : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift)F2: Color
F7 : Load Setup Defaults
Figure-9 System Monitor Setup Menu
The following pages tell you the options of each item and describe the
meaning of each option.
Item Option Description
• CPUFAN Speed
BAKFAN
CHSFAN
RPM (Revolution Per Minute) Speed of fan
which is connected to the fan header CPUFAN,
BAKFAN or CHSFAN. Fan speed value is
based on an assumption that tachometer signal is
two pulses per revolution; In other cases, you
should regard it relatively.
• + 3.3V,
VTT (+1.5) Voltage,
+ 5V,
VCCVID (CPU) Voltage,
+12 V,
- 12 V,
- 5 V.
Display current Voltage value including all the
most important voltages of the mainboard.
+3.3V, +5V, +12V, -12V, -5V are voltages from
the ATX power supply, VTT (+1.5) Voltage is
GTL Termination Voltage from the on board
regulator, and VCCVID (CPU) Voltage is CPU
Core Voltage from the on board switching
Power Supply.
• Chassis Status
Closed
Opened
The chassis is closed currently.
The chassis is opened currently.
Supervisor/User Password
When you select this function, the following message will appear at the center
of the screen to assist you in creating a password.
ENTER PASSWORD
Type the password, up to eight characters, and press <Enter>. The password
typed now will clear any previously entered password from CMOS memory.
You will be asked to confirm the password. Type the password again and
press <Enter>. You may also press <Esc> to abort the selection and not enter
a password.
