AWARD BIOS Description
3 - 14
IRQ-3 assigned to : Legacy ISA Used MEM base addr : N/A
IRQ-4 assigned to : Legacy ISA
IRQ-5 assigned to : PCI/ISA PnP
IRQ-7 assigned to : Legacy ISA
IRQ-9 assigned to : PCI/ISA PnP
IRQ-10 assigned to : PCI/ISA PnP
IRQ-11 assigned to : PCI/ISA PnP
IRQ-12 assigned to : PCI/ISA PnP
IRQ-14 assigned to : Legacy ISA
IRQ-15 assigned to : Legacy ISA
DMA-0 assigned to : PCI/ISA PnP
DMA-1 assigned to : PCI/ISA PnP
DMA-3 assigned to : PCI/ISA PnP
DMA-4 assigned to : PCI/ISA PnP
ESC: Quit ↑↓→← :Select Item
DMA-5 assigned to : PCI/ISA PnP F1 : Help PU/PD/+/- : Modify
DMA-6 assigned to : PCI/ISA PnP F5 : Old Values (Shift)F2 : Color
DMA-7 assigned to : PCI/ISA PnP F7 : Load Setup Defaults
Figure-7 PNP/PCI Configuration Setup Menu
The following pages will tell you the options of each item and describe the
meaning of each option.
Item Option Description
• PNP OS Installed
Yes
No
Device resource assigned by PnP OS.
Device resource assigned by BIOS.
• Resources Controlled By
Manual
Auto
Assign system resources (IRQ and
DMA) manually by user.
Assign system resources (IRQ and
DMA) automatically by BIOS.
• Force Update ESCD
Enabled
Disabled
The system BIOS will force updating
ESCD once, then automatically set
this item Disable.
Disable force update ESCD function.
• IRQ-3∼IRQ-15 assigned
to
Legacy ISA
PCI/ISA PnP
The specified IRQ-x will be assigned
to ISA only.
The specified IRQ-x will be assigned
to ISA or PCI.
• DMA-0∼DMA-7
assigned to
Legacy ISA
PCI/ISA PnP
The specified DMA-x will be assigned
to ISA only.
The specified DMA-x will be assigned
to ISA or PCI.
• PCI IDE IRQ Map
PCI-AUTO
The BIOS will scan for PCI IDE
To Next Page
