CAUTIONS
• This equipment must be earthed. It can possibly cause electrical shock if grounding is not
perfect. Do not use an extension cable. Otherwise it can cause electric fire or shock.
• The mains supply in the house must be equipped with an earth leak switch. If it is not
equipped with an earth leak switch this could result in electrical shocks and fire.
Perform the drainage/piping work according to the installation instruction.
• If there is a defect in the drainage/piping work, water could leak from the unit and household
goods could get wet and be damaged.
2. ITEMS PACKED WITH THE UNIT
2.1 ITEMS PACKED WITH THE UNIT (for SC 33xx models)
Number Name of Accessories Quantity
1 Installation plate 1
2 Clip Anchor 8
3 Self-tapping screw ‘A’ ST 3.9x25 8
4 Seal 1
5 Drain joint 1
6 Connecting pipe assembly 1
7 Remote controller 1
8 Self-tapping screw ‘B’ ST 2.9x10 2
9 Remote controller holder 1
2.2 ITEMS PACKED WITH THE UNIT (for S 33xx models)
Number Name of Accessories Quantity
1 Installation plate 1
2 Clip Anchor 8
3 Self-tapping screw ‘A’ ST 3.9x25 8
4 Seal 1
5 Drain joint 1
6
Connecting pipe
assembly
Liquid side
Ø 6.35 (< 6.5 kW model)
Ø 9.53 (> 6.5 kW model)
Not included
Gas side
Ø 9.53 (< 3.5 kW model)
Ø 12.7 (≥ 3.5 kW model)
Ø 16.0 (≥ 6.5 kW model)
7 Remote controller 1
8 Self-tapping screw ‘B’ ST 2.9x10 2
9 Remote controller holder 1
G
NOTE!
Except the above provided parts, the other parts needed during installation are to be purchased
separately by the buyer of the air conditioner.
