Qlima S(C) 33xx User Manual

52
b. If the wall is made of brick, concrete or the like, drill eight (8) 5mm diameter holes in the wall. Insert
clip anchor  for appropriate mounting screws .
c. Fit the installation plate  on the wall with eight (8) type “A” screws .
G
REMARK
Mount the mounting plate and drill the holes in the wall corresponding to the material of the
wall and the mounting points on the mounting plate in question (dimensions are in “mm” unless
otherwise indicated).
270~370
878
659
133
40
40
270
27
6
55
55
39
70
750
45
250
70
------------------------
293
920
50
50
815
40
285
90
40
45
------------------------
Correct orientation
of Installation Plate
Figure 8
S3325
SC3325
4
52
