3 – Managing Fabrics
Zoning a Fabric
3-46 59097-02 B
S
Create Zone button - create a new zone
Create Alias button - create another name for a set of objects
Add Member button - adds selected port/device to a zone
Remove Member button - delete the selected zone from a zone
set, or delete the selected port/device from a zone
Switch port icon – not logged in
Switch port icon – logged in
NL_Port (loop) device icon – logged in to fabric
NL_Port (loop) device icon – not logged in to fabric
N_Port device icon – logged in to fabric
N_Port device icon – not logged in to fabric
Table 3-4. Edit Zoning Dialog Tool Bar Buttons and Icons (Continued)
Tool Bar Button Description
