QNAP TS-1677X Series - Page 7

Component TS-1677X
USB ports 8 x USB 3.0
• Front:
• 1 x USB 3.0 Type-A
Note
You can use the One Touch Copy button with this port.
• 1 x USB 3.0 Type-C
• Back: 6 x USB 3.0 Type-A
HDMI outputs Optional: PCIe expansion card
Audio • 2 x 3.5 mm dynamic microphone jacks
• 1 x 3.5 mm line-out jack
• 1 x speaker
• Alarm buzzer
Note
You cannot use the speakers and the line-out jack
simultaneously.
Interface
Display panel Monochrome backlit LCD display with Enter and Select buttons
IR sensor 1
Note
• The IR sensor requires a graphics card.
• The QNAP RM-IR004 remote control is an optional
separate purchase.
Buttons • LCD enter
• LCD select
• Power
• USB One Touch Copy
• Reset
• Power supply unit
Dimensions
Form factor Tower
Dimensions (H x W x D) 303.84 x 369.89 x 319.8 mm
11.96 x 14.56 x 12.59 in
Net weight 13.39 kg (29.52 lbs)
Other
Power supply unit 550W, 100-240V AC, 50/60Hz
TS-1677X User Guide
Product Overview 6
