QNAP TS-433-4G User Manual

Methods User Actions
Enter manually a. Select Input Manually.
b. Specify the date and time.
The NAS date and time will be the same as the
congured time.
Synchronize with an Internet time server
automatically
Click Synchronize with an Internet time server
automatically.
The NAS time will be the same as the NTP server.
9. Click Next.
The Congure the network settings screen appears.
10. Congure the network settings using any of the following methods.
Methods User Actions
Obtain an IP address automatically (DHCP) Select Obtain an IP address automatically (DHCP)
The system automatically detects and congures the
IP address settings.
Use static IP address a. Select Use static IP address.
The IP address conguration page appears.
b. Specify the following IP address congurations:
• Interface
• IP Address
• Subnet Mask
• Default Gateway
• Primary DNS server
• Secondary DNS server
11. Click Next.
The Thunderbolt Connection page appears.
Note
This page only appears if your device supports Thunderbolt. You will need to connect your
device to a computer using a Thunderbolt cable.
12. Click Next.
The Summary screen appears.
13. Review the settings.
14. Click Apply.
A conrmation message appears.
Warning
Clicking Conrm deletes all data on the drive before installing QTS.
15. Click Conrm.
QTS is installed.
TS-433 User Guide
Installation and Conguration 22

QNAP TS-433-4G Specifications

General

Memory	4 GB DDR4 (non-expandable)
Drive Bays	4
Flash Memory	4GB eMMC
Hot-swappable	Yes
M.2 SSD Slot	No
Form Factor	Tower
Drive Compatibility	3.5" SATA HDD, 2.5" SATA HDD/SSD
HDMI Output	No
Maximum Internal Raw Capacity	80 TB (20 TB drive x 4)
Operating System	QTS
Fan	1 x 120mm
USB Ports	2 x USB 3.2 Gen 1
