b. Remove the fans.
13. Remove the top bracket from the chassis.
a. Remove the screws that secure the top bracket to the chassis.
Note
• The at head M3x4 screws require a Phillips #2 screwdriver.
• A torque of 7 kgf.cm (6.08 lbf.in) ± 0.5 kgf.cm (0.43 lbf.in) is recommended for
electric screwdrivers.
b. Slide back the top bracket to remove it from the chassis.
| NAS Repair Manual
Category D NAS Models 106
