14. Slide each drive tray back into the NAS.
Important
Each drive must be returned to their original bay.
TS-h1677AXU-RP components and screws
Note
The information presented here apply only to the representative model of the NAS category.
While all models within a NAS category have the same general structural design, their
components and screws may dier in size, quantity, and other specications.
Important
Recommended torque values are provided for electric screwdrivers. To avoid damage to the
screw or component, the actual torque setting should not exceed ± 0.5 kgf.cm (0.43 lbf.in) of
the recommended value, unless specied otherwise.
| NAS Repair Manual
Category E NAS Models 170
